Technical Parameters Main Feature
1.Strong decoding ability:embedded high-performance processing chip,with international advanced core algorithms,the data processing is accurate and reliable.
2.Great reading angle:support reading for angles±60°（left and right）±40°（front and rear）±360°（rotation）.
3.A number of reading mode:support manual and automatic scanning and other methods.
4.Support for multi-code system:recognizes one-dimensional bar code such as Code 128,EAN-13,EAN-8,Code39,Code93,UPC-A,and mainstream two-dimensional bar code such as QR Code DataMatrix,Chinese-Sensible Code,PDF417.
5.High identification accuracy:set with professional sensor,it has a wide range of depth of field,high sensitivity and low-contrast printing requirements.
6.Faster recognition:can read bar code information accurately and quickly,reduce the intensity of work effectively.
| Reading Parameters | ||
| Reading mode | CMOS,gray scale | |
| Resolution Ratio | 752×480 pixels | |
| Symbologies | Two-Dimensional Code | GM,MICRO QR,MICRO PDF417,QR Code,Data Matrix,Chinese-Sensible Code,etc. |
| One-Dimensional Code | Code 128,EAN-13,EAN-8,Code39,code93,UPC-A,etc. | |
| Reading Precision | ≥5mil | |
| Reading Depth | 40mm～300mm | |
| Print Contrast | ≥20% | |
| Barcode Rotation Sensitivity | 360°@0°Pitch and 0°Skew | |
| Barcode Tilt Sensitivity | ±60°@0°Roll and 0°Pitch | |
| Barcode Deflection Sensitivity | ±40°@0°Roll and 0°Skew | |
| Ambient Light | 0～100000 LUX | |
| Illumination LED light source | Visible Light-emitting Diode(630nm) | |
| Indicator LED light source | Visible Light-emitting Diode(535nm) or Laser LED Diode | |
| Interface | USB Virtual COM Port/USB HID/RS232 | |
| Triggering Mode | Manual/Automatic | |
| Prompting Mode | Buzzers/LED Indicating Lamp | |
| Setting Mode | Set by Computer online/Reading Code | |
| Electrical Characteristics | ||
| Input Voltage | DC 5V | |
| Current | Maximum Currrent | 350mA |
| Operating Current | 300mA | |
| Standby Current | 68mA | |
| Power Consumption | Maximum Power Consumption | 1.75W |
| Operating Power Consumption | 1.5W | |
| Standby Power Consumption | 0.34W | |
| Working Environment | ||
| Working Temperature | -5℃～＋45℃ | |
| Storage Temperature | -40℃～＋60℃ | |
| Working Humidity | 5%～95% (No Condensation) | |
| Waterproof & Dustproof | IP54 | |
| Physical Parameters | ||
| Module Size | 70mm×48mm×23.5mm | |
| Mounting Holes | 30mm×31mm | |
| Cable Length | 1.5m (Accordance with requirements to customize) | |
| Weight | 58g | |
| Security level | EMC:EN55022,EN55024 | |
| Electrical Safety：EN60950-1 | ||
| Light Safety：EN62471：2008 | ||
| Waterproof and dustproof Sealing Rating:IP54 | ||
| (The product is subject to real object,configuration changes will have no other notice.) | ||
