Technical Parameters Main Feature
1.Operating system:using the Linux operating system.
2.The collection of application:support 50000PLU,support NFC.
3.Strong Performance:using Single-chip high performance ARM security CPU and large capacity memory.
4.Flexible configuration:providing a variety of flexible communication mode.
5.High speed printing:build-in high-speed thermal printer,easy to load paper.
| Items | Specifications | |
| CPU | 32 bit high performance ARM926EJ@384 MHz | |
| Operating System | LINUX 2.6.36 | |
| Memorizer | Flash ：128MBytes，can be extended to a maximum of 512M DDR : 32 MBytes SDRAM，can be extended to a maximum of 128M | |
| Number of PLUs for programming | >50000 | |
| Departments | High class division categories 8,It has 99 sub categories each class | |
| Operators | The maximum can reach 255 | |
| Tax groups | 8 tax groups | |
| Cashier Register Types | Cash,Credit card,Foreign currency(With 6 kinds of foreign currencies) | |
| Tax Inspection Module(option) | Electronic Journal （Max 4Gb） / Fiscal Memory Vessel （Max 1Gb） / lead seal | |
| Screen | Operater display | 320*240 3.5" TFT LCD Color display |
| Customer display | 128*32 Dot matrix LCD monochrome display | |
| Keyboard | 40 keys | |
| Printer | 58mm high speed thermal printer, The maximun diameter of paper roll is 40mm | |
| Development Language | C/C++ | |
| Communication | 2G : GPRS( 850 / 900 / 1800 / 1900 ) MHz | |
| SIM Card Reader | 1 set,support 1.8V、3.0V | |
| SAM Card Reader | 1set，ISO7816 standard | |
| Physical Interface | USB Host*1 / USB Device*1 / Serial Port*1 / External Power IN*1 /Ethernet Port*1 / Cash Drawer Port*1 | |
| Language | Chinese,English,French,German,Turkish,etc ( support multiple languages,display and print ) | |
| Power Adapter | DC 12V 3A | |
| Outline Dimension | 200mm×166mm×52mm ( L×W×H ) | |
| Weight | 522g | |
| Environmental Requirements | Working temperature：-10℃～+45℃；Storage temperature：-40℃～+70℃ ; Relative humidity：5℅～95℅（No condensation） | |
| Foundation Certificate | CE、CCC（Certification according to customer requirements） | |
(The information shown here is indicative only,If there is inconsistency between the specification and the actual product,the actual product shall govern.) | ||
